Tanzo C 18 Lt Otoklav
Kategori
Marka
Stok Kodu
M6T3BRT4WG
Sterilizasyon
Fiyat
0,00 TL + KDV
Set içerigi:
- 18 lt B sınıfı Otoklav
- Distile Su cihazı
- Poşet Kapama Cihazı
18 Litre hacim
Europan B standart
Üstünde su deposu tasarımı ile daha kolay temizlenmesi EN13060
standartlarına uygun hale getirir. Avrupa B standartlarına uygun 3
ön vakum ve vakum kurutma ile nem oranı % 0.2 den azdır.
Vakum ölçümü 0.8 bar'a kadar ulaşır.Poşetli yada poşetsiz olarak
multi-diyafram ek borulu,A Tipi oyuk tüm tıbbi aletler sterilize
edilir.Su buharı penetrasyonu ölçen Bowie & dick testi mevcuttur.
Model List
|
Model
|
Voltage/Power
|
Chamber Size
|
Outside Size
|
Packing Size
|
Net Weight
|
|
TANZO C12
|
220V/1400W
|
Φ192×320
|
560×470×400
|
655×560×495
|
43
|
|
TANZO C18
|
220V/1500W
|
Φ245×360
|
560×470×400
|
655×560×495
|
47
|
|
TANZO C23
|
220V/1700W
|
Φ245×470
|
675×470×400
|
765×560×495
|
53
|
Main Features
|
Sterilization Class
|
CLASS B
|
|
Sterilization Temperature
|
121℃，134℃
|
|
Special Program
|
HIV, HBV long-sterilization program
|
|
Dry System
|
Vacuum drying system
|
|
Display
|
High-light LED tube display
|
|
Testing System
|
Bowie&Dick Test
Vacuum Test
Helix Test
|
|
Control Precision
|
Temperature: 1℃
Pressure: 0.1bar
|
|
Sterilization Data
|
Optional Mini printer
|
|
Safety System
|
Relief valve
Hand lock door
Pressure lock system
Pressure or temperature over load protection
Alarm system
|
|
Water Supply System
|
Build-in water tank easy to clean
Cubage: 3.5 or 4L
|
|
Tray Holder
|
5 layers tray holder with 3 trays
|
|
Chamber
|
Medical stainless steel 304
Max working pressure:2.3bar
Min working pressure: -0.9bar
Max temperature: 145℃
|
|
Operation Temperature
|
5～40℃
|
|
Noise
|
<50db
|
|
Water consumption in one cycle
|
0.16L~0.18L
|
 |
High density air filter,eliminating impurity in air,ensuring the returned air dry and pure.
|
 |
Efficient double-head vacuum pump,low noise,vacuum ability could get -0.92Bar,double head ensure the balance during working and stable vacuum state in the chamber.
|
 |
Electronic data output,the sterilization information can be saved into memory disk as a txt file,in connection with computer to analysis,realizing digital sterilization.
|
 |
The multiplex tray holder of sterilizer is single stretching molding,painting and polishing treatment,with good compression bear and suit various load.It could set 5 trays on the holder simultaneously when revolve it 90°.
|
 |
Circular heating little difference in temperature.
Pressure-prevention and corruption-resistance makes it highly reliable. Alloy heating loop protects against damage by no-water heating. Spcious cavity makes it easy to clean. |
 |
Original fuzzy control system driven by steam generator adoptsPWM(pulse with modulation),able
to discriminate the fine differences in temperature allowances and to adjust the modulated waves correspondingly thus making temperature rise at the same speed each time. |
 |
Chamber is made of purple glass surface copperplate，
plastically metamorphosed by the extrusion under 500-ton oil pressure. |
 |
Stable ULKA water pump made in Italy. |
 |
PHILIPS chip, famous world, powerful memory, process data fast and reliable.
|
 |
MAXIM is the worldwide leader of analog, mixed-signal, also head of high frequency and digital circuit research, development, manufacture, smooth circuit controlling.
|
 |
MOTOROLA precise-level pressure sensor, single crystal silicon thin film semiconductor strain gauge, can accurately sense the pressure within the sterilizer. |
 |
ST semiconductor, proud of high efficiency silicon, make the control more accurate and rapid.
|
 |
ATMEL Corporation, the world's advanced semiconductor design, manufacturing and marketing leader. ATMEL microprocessor, safe, reliable and feature-rich. |
 |
OMRON electromechanical conversion structure, powerful loading capacity, 10 life-time.
|
 |
SD Japan expert of temperature sensor, swift measurement, ready to deliver in time the temperature inside the sterilizer, superior.
|
